MIRAI Cold 30 T

(MC 30 C/W/T)
-40°C -110°C
Temperature range
30 kW
Motor power
Features
MIRAI Cold 30 T operates in a closed cycle configuration with air working indirectly inside of the refrigeration system.
MC 30 T is supplied with an additional heat exchanger. With use of industry-standard heat transfer fluids, MIRAI Cold machines are the ideal plug & play refrigeration solution for new systems as well as for retrofits.

MIRAI Cold 30 T – an air cycle refrigeration machine designed to provide and maintain ultra-low temperatures from -40 °C down to -110 °C in cooling processes in numerous industries, especially in the freeze-drying/lyophilization application.
Reduced power consumption up to
30%
Eco-Friendly
  • Air as Refrigerant
  • No need to refilling
  • Environmentally friendly
Temperature accuracy of
0.5°C
Cooling capacity & Power
MIRAI Cold 30 T (MC 30 C/W/T)
MIRAI Cold 30 T (MC 30 C/W/T)
MIRAI Cold 30 T
Technical Data
Refrigerant
Natural Air
Dimensions (WxDxH) ±1,5 cm
151x194x230 cm
Refrigeration Capacity
Up to 17.8 kW
Rated Motor Power
30 kW
Weight
2 300 kg
Noise Level
73 dB
Operation Cycle
Closed cycle
System Cooling Water
Water-cooled
Temperature Range
from -40 °C to -110 °C
Max Rotation Speed
51 000 rpm
