Features
MIRAI Cold 10 C/W/T is the most compact closed-cycle cooling machine in the MIRAI range, water-cooled and designed as the ideal solution for small-scale process cooling applications or freeze dryers. The system operates in a closed indirect refrigeration cycle, using Air as the refrigerant — a sustainable, eco-friendly, and fluorocarbon-free choice.
The machine is equipped with a factory-installed heat exchanger, compatible with different heat transfer fluids (HTF). The unit does not include any pumps or heating elements (heaters). You must supply your HTF to the integrated heat exchanger using your external pump.
Engineering support is required for proper system integration. The Mirai Intex engineering team will assist you with seamless integration of the unit into your setup — this applies to all C/W/T models. Optionally, the system can be delivered with remote monitoring and control capabilities, upon request.
Operating temperature range:
Standard: from –40 °C to –120 °C
Optional: down to –160 °C, available on request and depending on the properties of your HTF.
The machine is equipped with a factory-installed heat exchanger, compatible with different heat transfer fluids (HTF). The unit does not include any pumps or heating elements (heaters). You must supply your HTF to the integrated heat exchanger using your external pump.
Engineering support is required for proper system integration. The Mirai Intex engineering team will assist you with seamless integration of the unit into your setup — this applies to all C/W/T models. Optionally, the system can be delivered with remote monitoring and control capabilities, upon request.
Operating temperature range:
Standard: from –40 °C to –120 °C
Optional: down to –160 °C, available on request and depending on the properties of your HTF.
Reduced power consumption up to
30%
Eco-Friendly
- Air as Refrigerant
- No need to refilling
- Environmentally friendly
Temperature accuracy of
0.5°C
Cooling capacity & Power
MIRAI Cold 10 T (MC 10 C/W/T)
Additional Heat Exchanger
Closed cycle machines are factory equipped with an additional heat exchanger. The ultra-low temperature air is working in a closed loop by cooling down a heat transfer fluid in this additional heat exchanger.
Electrical Cabinet Air Filter Cartridge
The only part requiring regular attention. Each 9000 operating hours or by machine’s demand cartridge needs to be replaced. Simple task not requiring any special training or certification.
Control Panel
User-friendly interface and easy control of the machine is provided by 7” color touch screen panel. System is compatible with digital communication protocols ProfiNET, EtherCAT, EtherNET/IP, and Powerlink.
Technical Data
Refrigerant
Natural Air
Dimensions (WxDxH)
133x99x179 cm
Rated Motor Power
10 kW
Weight
790 kg
Noise Level
~70 dB
Operation Cycle
Closed cycle
System Cooling Water
Water-cooled
Temperature Range
from -40°C to -160°C
Max Rotation Speed
82 000 rpm
