Features
MIRAI Cold 80 T is a high-performance, closed-cycle refrigeration system based on the air cycle principle, designed to achieve and maintain ultra-low temperatures ranging from -40 °C to -120 °C (temperature range from -40℃ to -160℃ on request) . This powerful unit is ideal for a wide range of industrial applications, including freeze-drying (lyophilization), cryogenic cooling, thermal shock testing, and processes in the pharmaceutical, chemical, and aerospace industries.
The system uses air as a refrigerant, making it both environmentally friendly and highly reliable. The MIRAI Cold 80 T comes equipped with a built-in heat exchanger, optimized for use with HTF (heat transfer fluid), ensuring stable and efficient thermal exchange and compatibility with various working fluids.
An outdoor version of the unit is also available, enabling installation and operation in various climate conditions outside of indoor facilities.
Thanks to a variable-speed turbocompressor, the system can operate efficiently under partial load, adjusting its capacity to meet current demands while reducing energy consumption. Despite its power, the unit maintains a low noise level, making it suitable for noise-sensitive environments.
The system uses air as a refrigerant, making it both environmentally friendly and highly reliable. The MIRAI Cold 80 T comes equipped with a built-in heat exchanger, optimized for use with HTF (heat transfer fluid), ensuring stable and efficient thermal exchange and compatibility with various working fluids.
An outdoor version of the unit is also available, enabling installation and operation in various climate conditions outside of indoor facilities.
Thanks to a variable-speed turbocompressor, the system can operate efficiently under partial load, adjusting its capacity to meet current demands while reducing energy consumption. Despite its power, the unit maintains a low noise level, making it suitable for noise-sensitive environments.
Reduced power consumption up to
30%
Eco-Friendly
- Air as Refrigerant
- No need to refilling
- Environmentally friendly
Temperature accuracy of
0.5°C
Cooling capacity & Power
MIRAI Cold 80 T (MC 80 C/W/T)
Control Panel
User-friendly interface and easy control of the machine is provided by 7” color touch screen panel. System is compatible with digital communication protocols ProfiNET, EtherCAT, EtherNET/IP, and Powerlink.
Electrical Cabinet Air Filter Cartridges
The only part requiring regular attention. Each 9000 operating hours or by machine’s demand cartridges needs to be replaced. Simple task not requiring any special training or certification.
Additional Heat Exchanger
Closed cycle machines are factory equipped with an additional heat exchanger. The ultra-low temperature air is working in a closed loop by cooling down a heat transfer fluid in this additional heat exchanger.
System Pressurization Unit
With the optional System Pressurization Unit, MIRAI Cold machines are capable of matching required operating conditions and can charge or drain the appropriate amount of air from the refrigeration cycle. Required air purity for MIRAI Cold is 1.2.1 (accord
Technical Data
Refrigerant
Natural Air
Dimensions (WxDxH)
289x229x192 cm
Rated Motor Power
80 kW
Weight
4 340 kg
Noise Level
75 dB
Operation Cycle
Closed cycle
System Cooling Water
Water-cooled
Temperature Range
from -40°C to -110°C
Max Rotation Speed
45 000 rpm
Similar Products
MIRAI INTEX works only with the safest & most natural refrigerants.
MIRAI Cold 90 LNG
(MC 90 C/W/L)
-
-
-
-
MIRAI Cold 15 T
(MC 15 C/W/T)
-
-
-
-
MIRAI Cold 30 T
(MC 30 C/W/T)
-
-
-
-
MIRAI Cold 10 T
(MC 10 C/W/T)
-
-
-
-
MIRAI Cold 140 LNG
